Full inverter technology delivers faster heating, lower electricity bills, and near-silent operation.
| Model |
MPC140 |
MPXC220 |
MPXC320 |
MPX410S |
|
| Technology |
InverPad® Turbo (Patented) |
||||
| Operating Air Temperature (°C) |
-15°C - 43°C |
||||
| Advised pool volume (m3) * |
30~55 |
40~80 |
60~120 |
85~160 |
|
|
Performance (Air 27°C / Water 27°C / Humidity 80%) |
|||||
| Heating Capacity (kW) Turbo Mode | 14.0 | 22.5 | 31.5 | 40.5 | |
| Heating Capacity (kW) Perfect Mode |
10.9 |
18.0 |
26.8 |
34.5 |
|
| COP Range |
15.0~7.4 |
15.5~7.4 |
16.0~7.2 |
16.0~7.0 |
|
|
Average COP at 50% Speed |
6.5 |
7.0 |
6.9 |
7.0 |
|
|
Components |
|||||
|
Twin-Rotary DC Compressor |
|||||
|
230V 1Ph |
400V 3Ph |
||||
|
Sound |
|||||
|
Sound level at 1m dB(A) |
36.5~45.9 |
39.5~50.0 |
40.3~50.8 |
40.6~51.3 |
|
|
Sound level by 50% speed 1m dB(A) |
40.3 |
43.0 |
45.1 |
45.7 |
|
|
Sound level at 10m dB(A) |
16.5~25.9 |
19.5~29.8 |
20.3~30.8 |
20.6~31.3 |
|
|
Others |
|||||
|
Rated input power (kW) |
0.29~2.16 |
0.45~3.33 |
0.59~4.36 |
0.78~5.80 |
|
|
Input power at 50% Speed (kW) |
0.59 |
0.90 |
1.30 |
1.71 |
|
|
Rated input current (A) |
1.26~9.39 |
1.96~14.48 |
2.56~18.96 |
1.13~8.41 |
|
|
Advised water flux (m³/h) |
3~4 |
6~9 |
10~12 |
12~18 |
|
|
Water connection (mm) |
50 |
||||
|
Dimensions |
|||||
|
Net dimensions LxWxH (mm) |
750*504*656 |
980*504*756 |
1029*512*1107 |
1139*512*1106 |
|
|
Net weight (kg) |
73 |
91 |
136 |
160 |
|
|
Qty per 20'FT / 40'HQ (sets) |
78/162 |
40/126 |
18/80 |
16/72 |
|
